Name: Lug Type Butterfly Valve
Brand: Henan Haoyuan Intelligent Water Co., Ltd.
Availability: InStock

Lug Type Butterfly Valve

Product Details:

Place of Origin:	Henan, China

Contact Now

Detailed Product Description

Application:	General	Power:	Manual
Structure:	BUTTERFLY	Customized Support:	OEM
Product Name:	Lug Type Butterfly Valve	Keyword:	Lug Type Butterfly Valve
Calibration Range:	DN40~DN600	Pressure Level:	1.0~1.6MPa
Temperature Range:	-10℃~+100℃	Transmission Mode:	Manual
Applicable Media:	Water, Oil, Gas, Etc	Main Material:	Cast Iron, Carbon Steel, Stainless Steel, Etc.
Type:	Butterfly Valve

Lug Type Butterfly Valve

Product Description

Main Parts Materials:

No.	Part Name	Material
1	Body	Ductile iron/CS/SS
2	Seat	EPDM/NBR
3	Stem	Carbon steel/SS410/SS304/SS316
4	Disc	Ductile iron/CS/SS
5	Bushing	PTFE
6	O ring	NBR/EPDM
7	Lever	QT450-10
8	Pin	SS410/SS304/SS316

Specification

Main technical parameters
Nominal pressure:	PN10/PN16/PN25/PN40、125LB/150LB、5K/10K/16K
Face to face standard:	GB/T12221-2005、DIN3202
Test standard:	GB/T13927-2008、API598
Applicable media:	Water, oil, gas, etc.

Size	Max pressure (bar)	Min/Max Temp (℃)	Test Pressure (bar)
Size	Max pressure (bar)	Min/Max Temp (℃)			Shell	Seat
DN40-DN600	10.0/16.0	-10℃ +100℃	15.0/24.0	11.0/17.6

Company Profile

Company introduction

Henan Haoyuan Intelligent Water Co., Ltd. is a trading company specializing in industrial pipeline water instruments such as valves and flow meters. The company has a professional independent valve factory and flow meter factory; We have over 3 factories located in central China, including Henan Province, Zhengzhou City, and Kaifeng City. We have our own professional teams in research and development, production, sales, and after-sales service. In order to better serve our domestic and foreign customers, our company has established a trading company specializing in exporting various valves, flow meters, and other products. The company has obtained many certificates, including ISO9001, CE, etc. Welcome new and old customers to visit our factory and discuss cooperation.

FAQ

Q. Can I have my own Logo on the product?

A: Yes, OEM service is available.

Q.What information should I let you know if I want to get a quotation?

A: Size, design standard, material, package, Quantities, etc...

Please send us some pictures and designs for checking if possible so we can do best as your request. Otherwise, we will recommend relevant products with details for your reference.

Q: What is your terms of delivery?

A: We accept EXW,FOB,CIF,etc. You can choose the one which is the most convenient for you.

Q: What's the package and how do you ship the goods?

A: Usually is wood pallet as your requst. We usually ship by sea. Airline shipping is also optional.
